Microscopes
-
Basic Microscopes
Microscope, Portable
Just the right instrument to take in the field – totally portable, lightweight and almost indestructible. Its simple design, compact size and durable metal construction make it ideal for any weather conditions. This microscope yields 40x or 100x images illuminated by the built-in prism. Threaded, spring-loaded stage clips are secure and easy to use. No gears means it’s virtually maintenance-free. 10x Huygenian eyepiece with 4x or 10x achromatic objective produces a 40x or 100x image.
B10005 -
Basic Microscopes
Microscope, Elementary
Low cost basic microscope for use by school children to study natural science. Its light weight makes it suitable for field work as well. Focussing is by rack and pinion movement. A 84 x 76 mm stage with disc diaphragm and slide holding clips is provided. Illumination is by plano concave mirror reflector fitted under the stage. One Huygenian eye-piece x10 and one achromatic objective x10 are provided to give a sharp image of x100 magnification.
B10010 -
Basic Microscopes
Microscope, Junior
Economy model for beginners. Monocular body is inclinable upto 90° for ease of working. Mechanical tube length is standard 160 mm. Focussing is through rack & pinion arrangement. A fixed stage 110 x 100 mm is provided with stage clips and illumination is by plano concave mirror reflector. With x10 Huygenian eye-piece and x10 achromatic objective, giving x100 magnification.
B10015 -
Basic Microscopes
Microscope, Junior
Economy model for beginners. Monocular body is inclinable upto 90° for ease of working. Mechanical tube length is standard 160 mm. Focussing is through rack & pinion arrangement. A fixed stage 110 x 100 mm is provided with stage clips, and illumination is by plano concave mirror reflector. With x10 Huygenian eye-piece and a triple revolving nose-piece with three achromatic objectives x4, x10 and x20 giving magnification of x40 to x200.
B10017 -
Student Microscopes
Student Microscope, Model 20200
General Features
- Pressure die-cast parts to ensure strength and uniformity.
- Well, proportioned stable, rigid and vertical body inclinable through 90°.
- Mechanical tube length 160 mm.
- Separate knobs for coarse and fine focussing. Coarse knobs are with tension adjustment arrangement.
- Triple revolving nose-piece with international standard threads, with click stops ensuring correct centering.
- High-grade achromatic objectives and Huygenian eye-pieces for sharp and aberration-free image.
- Safety stopper to prevent damage to slides and objectives.
- Fixed square stage of 110×110 mm with two nonremovable stage clips.
- Sub-stage plano concave daylight mirror reflector in metal mount, replaceable by an electrical illuminator.
- Smooth black or scratch-resistant grey epoxy finish.
- Dust cover and cleaning cloth.
- Packed in moulded styrofoam box or wooden cabinet with lock and key.
- Stage fitted with disc diaphragm having six different apertures.
Optics
Eye-pieces: Huygenian x10 and x15
Objectives : Achromatic x10, and x40 (SL)
Magnification : x100 to x600B10065 -
Student Microscopes
Student Microscope, Model 20202
General Features
- Pressure die-cast parts to ensure strength and uniformity.
- Well, proportioned stable, rigid and vertical body inclinable through 90°.
- Mechanical tube length 160 mm.
- Separate knobs for coarse and fine focusing. Coarse knobs are with tension adjustment arrangement.
- Triple revolving nose-piece with international standard threads, with click stops ensuring correct centering.
- High-grade achromatic objectives and Huygenian eye-pieces for sharp and aberration-free image.
- Safety stopper to prevent damage to slides and objectives.
- Fixed square stage of 110×110 mm with two nonremovable stage clips.
- Sub-stage plano concave daylight mirror reflector in metal mount, replaceable by an electrical illuminator.
- Smooth black or scratch-resistant grey epoxy finish.
- Dust cover and cleaning cloth.
- Packed in moulded styrofoam box or wooden cabinet with lock and key.
- Stage fitted with iris diaphragm with a sub-stage two-lens Abbe Condenser N.A. 1.2, having helical motion
Optics
Eye-pieces: Huygenian x10 and x15
Objectives: Achromatic x10, and x40 (SL)
Magnification: x100 to x600B10070 -
Student Microscopes
Student Microscope, Model 20204
General Features
- Pressure die-cast parts to ensure strength and uniformity.
- Well, proportioned stable, rigid and vertical body inclinable through 90°.
- Mechanical tube length 160 mm.
- Separate knobs for coarse and fine focusing. Coarse knobs are with tension adjustment arrangement.
- Triple revolving nose-piece with international standard threads, with click stops ensuring correct centering.
- High-grade achromatic objectives and Huygenian eye-pieces for sharp and aberration-free images.
- Safety stopper to prevent damage to slides and objectives.
- Fixed square stage of 110×110 mm with two nonremovable stage clips.
- Sub-stage plano concave daylight mirror reflector in metal mount, replaceable by an electrical illuminator.
- Smooth black or scratch-resistant grey epoxy finish.
- Dust cover and cleaning cloth.
- Packed in moulded styrofoam box or wooden cabinet with lock and key.
- Stage fitted with iris diaphragm with a sub-stage two-lens Abbe Condenser N.A. 1.2, with rack and pinion movement.
Optics
Eye-pieces: Huygenian x10 and x15
Objectives: Achromatic x10, and x40 (SL)
Magnification: x100 to x600B10075 -
Student Microscopes
Pathological Microscope, Model 20208
This is a standardized microscope for medical institutions and pathological laboratories.
General Features
- Pressure die-cast parts to ensure strength and uniformity.
- Well, proportioned stable, rigid and vertical body inclinable through 90°.
- Mechanical tube length 160 mm.
- Separate knobs for coarse and fine focusing. Coarse knobs are with tension adjustment arrangement.
- Fine motion knob is graduated to read to 0.002 mm.
- Triple revolving nose-piece with international standard threads, with click stops ensuring correct centering.
- High-grade achromatic objectives and Huygenian eye-pieces for sharp and aberration-free images.
- Safety stopper to prevent damage to slides and objectives.
- Fixed square stage of 110×110 mm, fitted with detachable graduated mechanical stage.
- Sub-stage plano concave daylight mirror reflector in metal mount, replaceable by an electrical illuminator.
- A sub-stage iris diaphragm with Abbe condenser N.A.1.2 which moves up and down with rack and pinion motion.
- Smooth black or scratch-resistant grey epoxy finish.
- Dust cover and cleaning cloth.
- Packed in moulded styrofoam box or wooden cabinet with lock and key.
- Fitted with detachable graduated mechanical stage.
Optics
Eye Pieces: Huygenian x5, x10, x15 (any two)
Objectives: Achromatic x10, x40 (spring loaded) and x100 (spring loaded) oil immersionB10080 -
Student Microscopes
Student Microscope, Inclined
General Features
- Well proportioned stable, rigid and vertical body inclinable through 90°.
- Eye tube is inclined at 45°.
- Separate knobs for coarse and fine focusing. Coarse knobs are with tension adjustment arrangement.
- Triple revolving nose-piece with international standard threads, with click stop ensuring correct centering.
- Safety stopper to prevent damage to slides and objectives.
- Fixed square stage of 110×110 mm with two nonremovable stage clips.
- Sub-stage plano concave daylight mirror reflector in metal mount, replaceable by an electrical illuminator.
- Smooth black or scratch-resistant grey epoxy finish.
- Dust cover and cleaning cloth.
- Packed in moulded styrofoam box or wooden cabinet with lock and key.
Optics
Eyepieces: Wide Field x10 and x15
Objectives: Achromatic x4, x10 and x40 (SL)
Magnification: x40 to x400B10090
