Electricity
-
-
Electricity
Wheatstone Bridge, Two Gap
Comprising a resistance wire (SWG 26) stretched along a meter scale subdivided in mm and marked every cm. is clamped to stout brass plates so as to avoid end errors. A plated brass strip with 4 mm socket terminal is fitted along the meter rule to provide a two-gap system for normal Wheatstone bridge work. Complete with jockey.
PH50401 -
Electricity
Wheatstone Bridge, Four Gap
Four gap systems, enabling two additional resistances to be interpolated in the additional gaps, enable greater accuracy of measurement by reducing unwanted resistance to a minimum. Two brass strips are provided to close the gaps when so required. Complete with jockey.
PH50404 -
Electricity
Slide Wire Wheatstone Bridge
Consists of a resistance wire with a sliding contact and a strip of aluminum to provide two “arms” of the bridge for known and unknown resistance. Strips of heavy aluminum are provided with a single gap in each of two arms for the resistance. All components are mounted on a heavy sheet metal base. With Instructions.
PH50410 -
Electricity
Resistance Demonstration Set
Resistance Demonstration Set demonstrates the relation between resistance and cross-section of different wires. This set has 2 copper and 2 nichrome wires of different diameters. A pair of color-coded terminal used for power supply connection. This set uses 6V DC to operate.
PH50420 -
Electricity
Resistance Substitution Box
Set of 12 preferred value carbon resistors with rotary selection switch, in a box. Values are 33 Ω (10 W), 100 Ω (10 W), 330 Ω (5 W) 1 kΩ (1 W), 3.3 kΩ (1 W), 10 kΩ (0.25 W), 33 kΩ (0.25 W), 100 kΩ (0.25 W), 330 kΩ (0.25 W), 1 MΩ (0.25 W), 3.3 MΩ (0.25 W) and 10 MΩ (0.25 W).
PH50430 -
Electricity
Resistance Substitution Box
Resistance Substitution Box is a convenient instrument for determining the desired resistance values in circuits under design or test. This resistance substitution box has 12 different values 100 Ω, 220 Ω, 470 Ω, 1 kΩ, 2 kΩ, 4kΩ, 10 kΩ, 22 kΩ, 47 kΩ, 100 kΩ, 220 kΩ and 470 kΩ . All resistors are precision 1% resistors and are of 1-watt rating. Selected resistor can be attached in any circuit with 4mm two red safety sockets.
PH50430N -
Electricity
Resistor Set
Consisting of six resisters of resistances with different current ratings. The resistors can be used in either the series or parallel mode. The resistors can be connected to any of the desired circuits through the safety sockets provided on the top of the kit for each resistor separately. Accuracy ± 5%. The specifications of each resistor are printed on the top panel of the kit. Mounted in moulded box.
PH50437 -
Electricity
Resistance Box
Resistance Box kit is an excellent device, which provides a very good learning technique in making different combinations of resistances, either in series or in parallel; or in both ways, to obtain the desired value of resistance for any circuit application. It consists of 10 resistors of equal values, 10 Ω, 2 W. These resistances have ± 1% tolerance.
PH50438 -
